PREVENTIVE MAINTENANCE
CONVENIENT JOG DIAL
Easy to dispense, zero splash, hygienic dial delivers
desired volume of water.
ERROR INDICATIONS:
In the event of failure of pump and solenoid valve, service indicator
will start blinking @ 0.2 second with buzzer sound.
If UV intensity is less than adequate for disinfection of water,
service indicator will start blinking @ 0.2 second with buzzer sound
and also UV indicator will be solid
System will shut off in both the cases to deliver you the promise of
safe water or no water.
In case of low pressure condition ( Input water pressure is not
adequate ) then tank indication will blink
13 14
INSTALLATION INSTRUCTIONS
1. Open the carton and take out the following items from accessory box for installation:
a. Diverter valve
b. Mounting plate with plastic inserts and mounting screws
c. PL 4 pipe-White and blue
2. Select an appropriate water connection point.
3. Please note water purifier is connected to ambient temperature water supply only.
4. Fix diverter valve with the help of pipe wrench/plumbing equipments at selected
water point.
5. For wall mounting: Align the mounting plate at appropriate height and fix it with the
help of mounting screws. Hang the water purifier on mounting plate.
OR
Place the water purifier on counter top.
6. Fix the water inlet pipe (white pipe) from diverter valve to the feed water inlet port of
water purifier and open the diverter valve. Ensure there is no leakage of water
and bending of pipe at any point.
7. Outlet pipe (blue pipe) is connected to flushed water outlet port of purifier.
8. Fix the power plug into a 3 pin socket.
9. Switch ON the mains, unit will start working.
10. It is advised to drain the first fill of water tank after installation of the water purifier
or after changing the filters. This water can be used for washing, cleaning and
other household purpose.
If preventive maintenance is not attended in time, the service indication
will start blinking @ 0.5 second. Please call Havells Service to attend
the machine for preventive maintenance.
CAUTION: CAUTION: Before installation/mounting:-Flush all filters thoroughly
and independently for 3 minutes - 5 minutes to remove fine particles &
preservatives present in filters.
Check input water pressure. Use booster pump if feed water pressure is less than
0.041 MPa (6 psi) if it is more than 0.21 MPa (30 psi) use the PRV (Pressure reducing
valve). If the input water iron content is more than 0.3 mg/L (ppm), use of iron
remover is recommended as a pre-treatment. If input water turbidity is more than
5 NTU, use of Pre filter is suggested.
The appliance is intended to be permanently connected to the water mains and not
connected by a hose-set.
