Note: Four display resource types of this monitor are: FPV interface, DVR interface ,
External video input interface and HDMI interface.Use LETF key(shortcut key )
to switch the interface.
FPV Interface Descriptions
FPV interface is the default boot interface.
Voltage indicator: input voltage value is displayed; Display from 10V to 26 V. When
the battery is low, the menu turns red and starts flashing. When the battery is too low,
the blue light flashes faster and faster in the lower left corner and the buzzer alarms.
Please replace the battery immediately to avoid damage to the battery.
Recording indicator: a red “R” flashes when DVR is working in the background.
Time indicator: monitor running time is displayed.
Signal strength indicator: the strength of both the signals received by ANT1 and
ANT2 is displayed.
DVR Interface :
00:30
RSSI/Channel in use
Voltage
Time
