Hawking HWREG1 User Manual

Hawking Technologies Hi-Gain Wireless-G Range Extender Configuration
17
Encryption
You can select “Disable”,“ WEP 64bits”, “WEP 128bits”, “WPA (TKIP)” or
“WPA2 (AES)” encryption methods.
Key Format
This is only used when you select “ WEP 64bits” or “WEP 128bits”
encryption method. You may select to select ASCII Characters
(alphanumeric format) or Hexadecimal Digits (in the “A-F”, “a-f” and “0-9”
range) to be the WEP Key. For example:
ASCII Characters: guest
Hexadecimal Digits: 12345abcde
WEP Key
This is only used when you select “ WEP 64bits” or “WEP 128bits”
encryption method. The WEP key is used to encrypt data transmitted
between the bridged Range Extenders. Fill the text box by following the
rules below.
64-bit WEP: input 10-digit Hex values (in the “A-F”, “a-f” and “0-9” range)
or 5-digit ASCII character as the encryption keys .
128-bit WEP: input 26-digit Hex values (in the “A-F”, “a-f” and “0-9”
range) or 10-digit ASCII characters as the encryption keys.
Pre-shared Key Format You may select to select Passphrase (alphanumeric format) or
Hexadecimal Digits (in the “A-F”, “a-f” and “0-9” range) to be the Pre-
shared Key. For example:
Passphrase: iamguest
Hexadecimal Digits: 12345abcde
Pre-shared Key The Pre-shared key is used to authenticate and encrypt data transmitted
between the bridged Range Extenders. Fill the text box by following the
rules below. Hex WEP: input 64-digit Hex values (in the “A-F”, “a-f” and
“0-9” range) or at least 8 character pass phrase as the pre-shared keys .
Click Apply button at the bottom of the screen to save the above configurations. You can now configure
other advance sections or start using the Range Extender.
