Hawking Technologies Hi-Gain Wireless-G Range Extender Configuration
19
WEP key length will provide higher level of security, but the throughput
will be lower.
Key Format You may select to select ASCII Characters (alphanumeric format) or
Hexadecimal Digits (in the “A-F”, “a-f” and “0-9” range) to be the WEP
Key. For example:
ASCII Characters: guest
Hexadecimal Digits: 12345abcde
Default Tx Key Select one of the four keys to encrypt your data. Only the key you select
it in the “Default key” will take effect.
Key 1 - Key 4 The WEP keys are used to encrypt data transmitted in the wireless
network. Fill the text box by following the rules below.
64-bit WEP: input 10-digit Hex values (in the “A-F”, “a-f” and “0-9” range)
or 5-digit ASCII character as the encryption keys .
128-bit WEP: input 26-digit Hex values (in the “A-F”, “a-f” and “0-9”
range) or 10-digit ASCII characters as the encryption keys.
Click Apply button at the bottom of the screen to save the above configurations. You can now configure
other advance sections or start using the Range Extender.
802.1x only
IEEE 802.1x is an authentication protocol. Every user must use a valid account to
login to this Range Extender before accessing the wireless LAN. The authentication
is processed by a RADIUS server. This mode only authenticates user by IEEE 802.1x,
but it does not encryption the data during communication.
Parameter Description
RADIUS Server IP address The IP address of external RADIUS server.
RADIUS Server Port The service port of the external RADIUS server.
RADIUS Server Password The password used by external RADIUS server.
