PRODUCT DESCRIPTION AND IDENTIFICATIONS
18
19
20
21
14
15
9
8
7
4
3
2
1
6
5
10
13
11
12
16
17
1. Lock off button
2. Upper handle
3. On/Off Switch
4. Battery
5. Locking knob for the auxiliary handle
6. Auxiliary Handle
7. Clamp for the auxiliary handle
8. Collar for rotating the auxiliary handle
90˚ for edge cutting
9. Locking knob for adjusting the length of
the telescopic pole
10. Telescopic pole
Not all the accessories illustrated or described are included in standard delivery.
11. Motor casing
12. Edging wheel
13. Cutting head connector
14. Protection guard
15. Locking button for the cutting head
16. Flower guard
17. Cutting head
18. Line blade
19. Line spool
20. Spool button
21. Cutting line
