Hayward E-Vac - Service Tools Overview; Diagnostic Scanner Tool

Table of Contents
TigerShark & TigerShark QC
Important safety instructions Page 1
Service Tools Page 2
Filter Removal/Cleaning and Drain Flaps Pages 4-6
Handle Removal Page 7
Venturi Removal Page 8
Bottom Lid Disassembly Pages 9-10
Side Cover Removal Pages 11-12
Drive Track and Idlers Pages 13-16
Power Cord and Motor Box Pages 17-27
Wheel Tube Brush and Bearings Pages 28-30
Using the Scanner Tool Pages 31-34
Power Supply and Flotation Cord Testing Page 35
Basic Operation Pages 36-37
Troubleshooting Pages 38-43
