Motor Box Removal
Page 61
When removing motor assembly without complete
removal of side cover,
gently separate motor output shaft from keyed
drive gear using a screwdriver.
The drive gear will remain in place. Be sure to
remove all 4 motor securing screws.
Remove 4 T20 screws securing motor to base.
