Page 22 (Power Cord and Motor Box Reassembly - Connector)
Hayward E-Vac - Power Cord and Motor Box Reassembly - Connector; Connector Installation Guidance
71 pages
Manual
Save Page as PDF
To Next Page
To Next Page
To Previous Page
To Previous Page
Loading...
Gently pull on cord to
disconnect and remove from motor.
Note that plug has tape
r on bottom side
to mate with rubber seal taper.
Power Cord & Motor Box Removal
Page 19
Note: Any time seal is removed
it is recommended to replace
special rubber seal.
21
23
