Connector must be installed with tab on
connector placed in mating hole of motor
assembly. The white wire must be inserted
on the tab side of the connector.
Note the order of the seals and washers.
Remember to mate the taper of the seal
and threaded plug.
Use the Torque driver and spanner wrench to install
and tighten the threaded plug. Tighten the threaded
plug until you feel the Torque wrench click or slip.
Power Cord & Motor Box Removal
Page 22
