Hayward E-Vac - Motor Assembly Details and Impeller

Remove 4 motor assembly
screws 2 from each end.
Location of motor screws when side cover is not
removed. It is possible to remove motor assembly
without removal of side cover. However, the 7 side
cover screws must be loosened on the motor
drive side.
Power Cord & Motor Box Removal
Page 24
