6. APPENDICES (continued)
ECP 15
N Ref. Description N Ref. Description
1 HWX32009210196 Front ABS panel 23 HWX20003242 Temperature sensor
2 HWX20003933 3-point terminal block 24 HWX20003242 Temperature sensor
3 HWX20003524
Start-up capacitor
CPS 98μF
25 HWX32009120006
Titanium/PVC
capacitor
4 HWX35122213 Grille 26 HWX35001401 Battery
5 HWX320921015 Front stiffener 27 HWX20002111
Controller protective
cover
6 HWX320921149 Rear stiffener 28 HWX950531188 7-segment controller
7 HWX32009210193 Frame 29 HWX32009210194 Right panel
8 HWX35002701 Fan blade 30 HWX20003242 Temperature sensor
9 HWX34043301 Fan motor 31 HWX32009220054 Protection cover
10 HWX32009210195 Left panel 32 HWX20011169 Compressor
11 HWX320921147 Motor bracket 33 HWX320921152 Electrical box cover
12 HWX320921148 Centre wall 34 HWX320921151 Electrical box
13 HWX20013605 High pressure switch 35 HWX20003501 Fan capacitor 3μF
14 HWX200014153 Schräder valve 36 HWX200037006
230V~/12V~
transformer
15 HWX32009210197 Top ABS cover 37 HWX20003920 3-point terminal block
16 HWX20001489 Restrictor 38 HWX950531145 PC1000 circuit board
17 HWX20011491 4-way valve 39 HWX20003676 Relay
18 HWX20003603 Low pressure switch 40 HWX200036007 Compressor switch
19 HWX20003242 Temperature sensor 41 HWX20003909 2-point terminal block
20 HWX351212001 Coil 42 HWX20003510
Compressor capacitor
60μF
21 HWX20041444
Filter (diam. 9.7- diam.
9.7)
43 HWX20009909 Capillary
22 HWX200036005 Flow detector
To Next Page
