USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
22
2.
3.
NOTE: For SVRS pump models, the SVRS feature is disabled during Quick Clean mode. When Quick Clean is pressed, the above message is displayed to alert
the user that SVRS is disabled, and that all bathers should exit the pool during Quick Clean. If bathers are in the water, pressing + will return the pump to
normal operation. If bathers are not in the water, pressing – will allow the pump to run in Quick Clean mode, where it will run at the Max allowed speed set in
the Configuration Menu for 60 minutes. When Quick Clean is selected for non-SVRS pump models, the pump will immediately proceed to Quick Clean mode.
4.
5.
6.
NOTE: The above message will be displayed while Quick Clean is running. Quick Clean mode expires after 60 min, and it may be cancelled early by pressing the
Stop/Resume button, at which time the pump would return to normal operation. Quick Clean can be extended up to 360 minutes with additional presses of the
Quick clean button. For non-SVRS pump models, the SVRS Inactive message will not be shown, and the Check System LED will not flash.
Remote Stop
1.
NOTE: The above message will be displayed when an installed remote stop switch is activated. The pump will remain stopped until the remote stop switch is
deactivated. See page 14 for more detail.
Maintenance
• Clean strainer basket regularly. Do NOT strike basket. Inspect cover gasket regularly and replace as necessary.
• Hayward pumps have self-lubricating motor bearings and shaft seals. No lubrication is necessary.
• Keep motor clean. Keep motor air vents free of obstructions to avoid damage. Do NOT use water to hose off motor.
• Occasionally, shaft seals must be replaced, due to wear or damage. Replace with genuine Hayward seal assembly kit. See “Shaft Seal Change Instructions”
on the following page.
Storage/Winterization
WARNING – Separation Hazard. Do not purge the system with compressed air. Purging the system with compressed air can cause components to
explode, with risk of severe injury or death to anyone nearby. Use only a low pressure (below 5 PSI), high volume blower when air purging the pump, filter,
or piping.
Screen
No bathers in water
during Quick Clean
Bathers in water?
+ yes or - no
Screen
SVRS Inactive
Quick Clean running
SVRS Inactive
3450 rpm for 60 min;
SVRS Inactive
press Resume to end
Screen
Remote Stop
is engaged
To Next Page
