USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
17
3. Preset Speed Setup Menu (see page 20 to program the 4 preset speeds)
a. Speed “X” Name (where “X” equals 1 through 4)
b. Speed “X” Speed (where “X” equals 1 through 4)
4. Diagnostics Menu (see page 21 to view product diagnostic information)
a. Display Firmware Revision
b. Drive Serial Number
c. Motor Drive Firmware Revisions
d. SVRS Revision (if applicable)
e. Event Log (if applicable)
Initial startup
After plumbing and wiring are complete, the variable speed drive must be configured prior to use. When power is applied to the drive for the first time, the fol-
lowing informational screens are displayed.
1.
2.
3.
NOTE: Speeds can be selected at this time to temporarily run the pump, however, it is recommended that the drive configuration and timers be set according to
individual installation site requirements (see page 19 for more details). At this point, pressing the MENU button will select the Configuration Menu.
Configuration Menu
1.
2.
3.
4.
5.
Press and hold < and > buttons for several seconds to unlock the Configuration
Menu.
Use the > button to enter the Configuration Menu.
Screen Buttons Used Comments
Configuration Menu
Locked
Configuration Menu
press > to enter
press +/- to change
or > view next item
Time: Th 1:27PM
+ change or > skip
Set Day and Time
Thursday 1:27p
Use + button to change clock setting.
Use > if clock is correct.
Adjust day/time setting.
Move to next selection, then move to next menu item.
< >
< >
+ -
< >
+ -
< >
Screen
Hayward Variable
Speed Pump
Thursday 1:27p
1725rpm 380 Watts
Timer 1 timer
will end at 11:45p
To Next Page
