Begin Using Quick Edit
From the Quick Main Menu Screen, select one of the following buttons and follow the directions on the next page to configure your equipment.
• Bodies of Water
• Backyard
• Sensors
• Interlocks/Add Interlock
• System Options
• Spa Side
If Bodies of Water is selected:
Select the body of water - Select the Body of Water that you would like to make changes to. Both bodies of water will have the same equipment options
for Quick Edit.
Body of Water is selected:
Select the Equipment that you would like to configure - The options are as follows: Filter Pumps, Heaters, Chemistry, Cleaners, Water Fea-
tures, Standalone Lights, Accessories, and Other Options. If the equipment is not already configured, then the buttons will appear as Add Heater, Add
Chemistry, etc. When the button is pressed with the word “Add” before it, then you will be taken through the full configuration for that equipment as
appears in the Configuration Wizard portion of this manual. Otherwise:
If FIlter Pumps is selected:
Select a Filter Pump - Once you select a filter pump, all of the options for that filter pump will appear on the next screen. These options
are as follows:
Name - Rename the Filter Pump to whatever name you desire.
Type - Change the type of Filter Pump that is configured (Single Speed, 2-Speed, or VSP)
HUA - Match the HUA (Hayward Unique Address) to the configured Filter Pump. This option only appears if the Filter Pump is configured
as a Variable Speed Pump.
Speed - Change the Minimum and Maximum Allowed Speeds of the Filter Pump as well as the Low, Medium and High speed settings.
This option only appears if the FIlter Pump is configured as a Variable Speed Pump.
Relay - Select the relay(s) that the Filter Pump is wired to. This option only appears if the Filter Pump is configured as a single speed
or 2-Speed pump.
Off for Valve Change - Select whether you want the Filter Pump to shut off while valves are turning.
Flow Monitoring - Select whether you want flow to be monitored in this Body of Water.
Priming - Select whether you want the Filter Pump to prime and the desired duration. This option only appears if the FIlter Pump is
configured as a 2-Speed or Variable Speed Pump.
Freeze Protect - Select whether you want the Filter Pump to turn on for Freeze Protection. Also set the Freeze Protect air temperature
threshold from this menu. Freeze protect operation can be overridden for a 60 minute period. (See Operation manual for more infor-
mation).
If Heating/Cooling is selected:
Add a Heater - Pressing “Add a Heater” from this screen will take you through the full configuration for adding a new heater. These steps
are described in the Configuration Wizard portion of this manual.
Add a Chiller - Pressing “Add a Chiller” from this screen will take you through the full configuration for adding a new chiller. These steps
are described in the Configuration Wizard portion of this manual.
General Heater Options - Pressing this button will take you to a screen will the following general options for heater operation:
Extend - Select whether you want Heater Extend enabled for this Body of Water.
Cooldown - Select whether you want Heater Cooldown enabled for this Body of Water.
Max Temperature - Select the Maximum Allowed Heater Setpoint Temperature for this Body of Water.
