9
Turn off pump before disassembling filter control valve.
Rotate lock ring counterclockwise for removal
of the cover assembly.
Remove cover assembly. If difficult to remove,
rock the base of the handle while pulling up.
Using handle, lift hub assembly out of the
body.
Step 2
Step 1
Valve: Winterization Disassembly
Remove seal carriers and check for wear.
Replace worn or damaged parts.
Step 4
X 2
Step 3
