RTN/M2
MOUNTING PREPARATION
10
5 plates max. for
height adjustment
5 plates max. for height adjustment
Upper module plate
Centering disc
(only up to 4.7 t
max. capacity)
Lateral stops
Cross‐bracket
(Anti‐liftoff device)
Air gap: 1 mm
Mounting base
(only up to 4.7 t
max. capacity)
Bearing
Dummy
Fig. 4.1 Fitting of the spacer plates with 4.7 t version
