HBK RTN/M2 - Dimensions; RTN;M2 LA Dimensions

15
RTN/M2
DIMENSIONS
6 DIMENSIONS
RTN/M2LA - Version with rubber‐metal bearing
60
8
111
8
30
8
153
17
only version with
stay rod
max. 5 spacer plates
(110 - 115 by
spacer plates)
230
100
100100
160
25
15
View from above
20
15
View from below
230
100
100100
160
25
15
15
20
Max. capacity 1 t ... 4,7 t
Perspective view
Dimensions in mm
(1mm = 0.03937 inches)
