RTN/M2
DIMENSIONS
16
RTN/M2LA - Version with rubber‐metal bearing
1022
65
148
10
10
151
255
max. 5 spacer plates
only version with stay rod
(150 - 155 by
spacer plates)
Max. capacity 10 t ... 22 t
Perspective view
310
140130
140
18
200
View from above
20
25
View from below
310
140130
140 200
25
20
18
20
20
Dimensions in mm
(1mm = 0.03937 inches)
