HBK RTN/M2 - Page 21

19
RTN/M2
DIMENSIONS
RTN/M2LB - Version with pendulum bearing
148
1010
151
max. 5 spacer plates
only version with stay rod
10
(150 - 155 by
spacer plates)
Max. capacity 10 t ... 22 t
Perspective view
310
140130
140
18
200
View from above
20
25
View from below
310
140130
140 200
25
20
18
65
255
20
20
Dimensions in mm
(1mm = 0.03937 inches)
