HBK RTN/M2 - Page 22

RTN/M2
DIMENSIONS
20
RTN/M2LB - Version with pendulum bearing
max. 5 spacer plates
only version with stay rod
85
188
12
12
193
(192 - 197 by
spacer plates)
View from above
View from below
Max. capacity 33 t
Perspective view
420
200155
200 280
35
420
200155
200 280
35
22
26
26
22
290
35
35
Dimensions in mm
(1mm = 0.03937 inches)
