RECEIPT & INSPECTION
After receiving, inspect the unit for any possible physical damage that may have
occurred during transportation. After unpacking the unit make sure the box contains:
• 1 x WPS-0100 (Temperature & Pressure Sensor)
• 2 x EPDM Flat Washers
• 1 x Dual unions, tailpieces - NPT, sweat, press
• 1 x Flow pipe and tube with connection ttings
• Instruction Manual
Make sure the part number on the unit corresponds to the part number on
the original box
STORAGE
The Sensorlinx™ Heat Meter should be kept in its original shipping carton prior to
installation. In order to retain the warranty coverage it should be stored properly:
• Store within an ambient temperature range of +10ºC to +40ºC
• If possible, store in an air-conditioned environment where the relative humidity is
less than 95%
• Do not store in places where the unit may come into contact with corrosive
gases or liquids
• Do not store in an area or upon an unstable surface where it may become
damaged due to falling
NAME AND PIN INFORMATION
The label displays the serial number which will match the serial number on your
actual HBX Sensorlinx™ Sensor, the lot number, the bar code and the products PIN.
Sync Code: APRE1234
PIN: 1A2B3
WiFi Pressure Sensor
WFS-0100
3068143
Conforms to EN 1434
Conforms to UL Standard 873
Certified to CSA C22.2 No 24
READY
SERVER
WI-FI
