GIpro X-type
Install Guide for GPX-H02 Harness Kit
For use with the following HONDA motorcycles:
CBF500 (2004-2008), CBR250R (2011),
NRX1800 (2004-2006), Valkyrie Rune (2004-2006),
VT750 Shadow (2008-2010),
VTX1300 (2003-2011), VTX1800 (2002-2004)
Disclaimer: Do not attempt to install the product if you don’t have basic mechanical skills.
HealTech Electronics Ltd. and its distributors shall not be liable for any loss or damage
caused by improper installation. If in doubt, please consult with your dealer.
1. Locate the Speed Sensor coupler. It is a 3-pole, natural color connector.
- CBF500:
Behind left side cover, in dust boot
- CBR250R:
Behind left side cover
- NRX1800, Valkyrie Rune:
Under seat and fuel tank at the right side, near ECM
- VT750:
Under rider’s seat in front left, in dust boot
- VTX1300, VTX1800:
Behind left side cover, under key switch, in dust boot
Confirmation:
Separate the Speed Sensor coupler (you might need to use a small flathead
screwdriver to get the coupler apart). Rotate the rear wheel while ignition is on.
The speedometer should indicate 0. If so, turn the ignition off and proceed to the
next step. Otherwise, if the speedometer registers a speed other than 0, you have
not disconnected the correct coupler and need to look again.
2. After separating the Speed Sensor coupler, plug in both the male and female
3-pole GIpro harness connectors. Make sure the connectors are fully seated.
If you have a SpeedoHealer installed, you have to connect the plugs in-line in the
following order:
Speed sensor male plug
Æ
GIpro
Æ
SH
Æ
bike female plug
