SETTING PEUKERT EXPONENT
When you select Battery Type (See Function F02 on Page 20), your Link 20 automati-
cally sets a Peukert exponent which is generally correct. However, your batteries may
have different characteristics than "average" and you may wish to change the exponent so
your Time Remaining and Light Bar displays will be as accurate as possible. To change
the Peukert exponent, proceed as follows:
Before you begin, select the Battery you wish to apply the new
exponent to: BAT 1 or BAT 2.
A. Press and hold the SET button for 3 seconds to enter Set Up mode. SEL appears
in the display. Press SEL and notice that the green
LED is on.
B. Press SEL again and note that the
light comes on. Continue to press the SEL
button until F08 appears in the display. (This will require eighteen presses of the SEL
button.) The right most green light bar indicator with the legend FUNC under it will be
lit.
C. Now press and hold the SET button. If Battery Type is set to #1 (liquid cells), the
default value of 1.25 (or the previously programmed value) will appear in the display. If
Battery Type #2 (gel cells) is selected, the default value of 1.11 (or the previously pro-
grammed value) will be displayed. The range of values is from 1.0 to 1.50.
Holding down the SET button will cause the display to increment in 0.01 steps, after 4
increments the display scrolls faster. When the value you want appears, release the SET
button. If you overshoot your capacity you will have to scroll all the way to 1.50 after
which the display will roll over to 1.00 and continue incrementing up.
D. After 10 seconds, if no keys are pressed, the Link 20 exits the Set Up mode and
the selected value is stored as the new Peukert's exponent and the display returns to
(Volts).
