HR4136-B1
HEART TECH ENTERPRISE CO., LTD. BEST SERVICE FROM HEART
10
Transmission Area (information only):
Stick antenna
Tag : TEXAS INSTRUMENTS 32mm Glass Transponder part number RI-TRP-DR2B
The transmission area diagram going through the center of the antenna and indicated on a flat surface
vertical to the antenna surface is as indicated below.
X
01122334455667788 99 10 11
Legend :
Normal area
Recommended area
Unrecommended area
X
Y
To Next Page
