7/11/2014 Heat & Glo • 7076-250C 3
Curve 100
TABLE OF CONTENTS
Safety Alert Key:
• DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury.
• WARNING! Indicates a hazardous situation which, if not avoided may result in death or serious injury.
• CAUTION! Indicates a hazardous situation which, if not avoided, may result in minor or moderate injury.
• NOTICE: Indicates practices which may cause damage to the appliance or to property.
1 Technical Data ......................................... 4
A. Installation ............................................................................ 4
B. Safety ................................................................................... 4
C. Type plates .......................................................................... 4
2 Installation & Assembly .......................... 5
A. Positioning Your Wood Burning Stove ................................. 5
B. Vertical Venting & Combustion Air ....................................... 5
C. Horizontal Venting................................................................ 5
D. Leveling the Unit .................................................................. 6
E. Position Near to Non-fl ammable Walls ................................ 6
F. Distance to Furniture: 1000 mm ........................................... 6
G. Distance to Flammable Walls .............................................. 6
H. Component Pack ................................................................. 6
I. Removal of Curve from Pallet................................................ 6
3 Dimensions & Clearances ...................... 7
A. Appliance Dimensions.......................................................... 7
B. Floor Protector ..................................................................... 8
C. Hearth Requirements ........................................................... 8
4 Operation ................................................. 10
A. General Use ....................................................................... 10
B. Lighting Instructions ........................................................... 10
C. Your First Fire .................................................................... 10
D. Fuels .................................................................................. 10
E. Primary Air ......................................................................... 12
F. Upper Air Control................................................................ 12
G. Secondary Air .................................................................... 12
H. Airwash System ................................................................. 12
I. Side Door Handle Operation .............................................. 13
J. Front Door Seal .................................................................. 13
5 Chimney Systems .................................. 14
A. Chimney Systems .............................................................. 14
B. Drafting............................................................................... 14
C. General Instructions for Flue System................................. 14
6 Maintenance............................................ 17
A. Ash Drawer ........................................................................ 17
B. Refractory........................................................................... 17
C. Baffl e Material .................................................................... 17
D. Proper Burn........................................................................ 17
E. Coated Surfaces ................................................................ 17
F. Cleaning the Glass ............................................................. 17
7 Troubleshooting ..................................... 18
8 Warranty .................................................. 19
9 Service Parts List ................................... 21
10 Reference Materials ............................... 23
