Installation, Operation & Maintenance AIR HANDLER SERIES Heat Controller, Inc.
WDG Blower
Airfl ow in CFM with wet coil and clean air fi lter
Model
Max
ESP
(in. wg)
Fan
Motor
(hp)
Range
Cooling Mode Dehumid Mode
Heating
Mode
Fan
Only
Mode
Aux/
Emerg
Mode
Stg 2 Stg 1 Stg 2 Stg 1 Stg 2 Stg 1
WDG
024
1.0 1/2
Default 700 525 550 425 750 600 350 850
Maximum 1000 800 800 600 1000 850 1000 1000
Minimum 600 450 550 400 600 450 300 700
WDG
036
0.9 1/2
Default 1050 800 850 650 1100 850 550 1350
Maximum 1500 1100 1200 900 1500 1100 1500 1500
Minimum 900 675 825 600 900 675 450 1350
WDG
048
1.0 1
Default 1400 1050 1100 850 1500 1150 700 1500
Maximum 2000 1500 1600 1200 2000 1500 2000 2000
Minimum 1200 900 1100 825 1200 900 600 1350
WDG
060
0.7 1
Default 1750 1300 1400 1050 1875 1450 875 1875
Maximum 2300 1900 2000 1500 2300 1900 2300 2300
Minimum 1500 1100 1375 1000 1500 1100 750 1500
Airfl ow is controlled within 5% up to the Max ESP shown with wet coil
