Installation, Operation & Maintenance AIR HANDLER SERIES Heat Controller, Inc.
Model Physical Data
Model 026-A 026-B 038-B 038-C 049-B 049-C 064-C
Emerson ECM Fan Motor & Blower in. [cm]
Liquid I.D. 3/8 [0.95] 3/8 [0.95] 3/8 [0.95] 3/8 [0.95] 3/8 [0.95] 3/8 [0.95] 3/8 [0.95]
Suction I.D. 3/4 [1.9] 3/4 [1.9] 7/8 [2.22] 7/8 [2.22] 7/8 [2.22] 7/8 [2.22] 7/8 [2.22]
Fan Motor Type/Speeds ECM Variable
Fan Motor (hp) 1/2 1
Blower Wheel Size (Dia x W)
in. [mm]
9 x 7 [229 x 178] 12 x 10 [305 x 254]
Air Coil Dimensions (H x W)
in. [mm]
3 - 2 Row 14 x 17 [356 x 432] 3 - 2 Row 24 x 17 [610 x 432]
3 - 3 Row 24x17
[610 x 432]
Filter Standard - 1” [25mm]
Throwaway
16 x 20 [406 x 508] 20 x 20 [508 x 508]
20 x 24
[508 x 610]
20 x 20
[508 x 508]
20 x 24 [508 x 610]
Weight - Operating lbs. [kg] 80 [36] 163 [74] 173 [78] 181 [82] 180 [82] 188 [85] 198 [90]
Weight - Packaged lbs. [kg] 96 [44] 179 [81] 198 [90] 206 [93] 218 [99] 226 [103] 236 [107]
024-B
024-C 036-C 036-D
048-C
048-D 060-D
Table 1: Physical Data
