Heatmaxx SRPT03 - Parts List

6
PARTS LIST
Please check the contents of the packaging as to whether anything is missing!
7
8
9
A
B
B
C
D
Part # Description Qty
1 Reflector dome 1
2 Emitter screen 1
3 Emitter screen shield 1
4 Burner column 1
5 Control knob 1
6 Door 1
7 Fixed panel 1
8 Base 1
9 Weight block 1
Hardware#
Description
Qty Picture
A M6 x 10 bolt 3
B M4 x 10 bolt 13
C 6mm Washer 4
D M6 x 14 bolt 4
