35 / 72
• Parts of the packaging (plastic bags, paper clips, etc.) do not leave within reach of children,
could be a possible source of danger. Do not let children play with plastic bags, foils or small
parts. There is a danger of swallowing or suffocating!
• Disposal must be made in accordance with the regulations in force in the country in which
the equipment was installed.
• Make sure that bags and containers of plastic material are left strewn freely in the environment
because they pollute it.
• If you have any doubt do not use the machine, but have it checked by an authorized service
center.
• The machine is shipped partially dismantled and packaged in a metal crate to protect it
during transport.
• Remove the crews and nuts connecting the upper crate to the base.
• Operation to be performed by two people. Lift the upper iron crate so as to free the machine
(fig. 3).
• Free the machine from the metal fasteners securing the 4 wheels to the base.
C To prevent damaging the blade deck and blade, move these to maximum height
during the downward movement of the base platform. Be very careful when
performing this delicate unpacking operation.
PACKAGE CONTENTS
1x body of tractor, 1x seat, 1x grass catcher, 1x steering wheel, 1x lever, 1x set of fasteners, 1x
battery, 1x charger, 1x instruction manual
Standard accessories are subject to change without notice.
This product requires assembly. The device must be assembled correctly before use.
ASSEMBLY
For storage and transport purposes, some components of the machine are not installed in
the factory and have to be assembled after unpacking.
Unpacking and completing the assembly should be done on a flat and stable surface, with
enough space for machine handling and its packaging, always making use of suitable equipment.
Follow the instructions below.
FITTING THE STEERING WHEEL
1. Put the machine on a flat surface and straighten up the front wheels.
2. Fit the steering wheel (fig. 4A) onto the protruding shaft (fig. 4B) and fasten it with
the screws (fig. 4C) and nuts (fig. 4D) supplied.
3. Tighten. Pull on the steering wheel to make sure it has been locked in place.
FITTING AND ADJUSTING THE SEAT
1. Fit the seat (fig. 5A) on the deck (fig. 5B) with the screws (fig. 5C).
2. Before tightening the 4 screws adjust the forward / backward position of the seat, to best
suit the driver.
SEAT ADJUSTMENT
1. To change the seat position, loosen the four fixing bolts and slide it along the slots.
2. Once you have found the right position, tighten the four screws.
manual_HECHT_5161_2019_EN.indd 35 11.03.2019 10:29:44
