3-40 TNC 407/TNC 415/TNC 425 9 Data interface 01.98
9 Data interface
The HEIDENHAIN contouring controls TNC 407 and TNC 415 have two data interfaces:
one RS-232-C/V.24 data interface and
one RS-422/V.11 data interface.
Both interfaces may be utilised. The operator decides which of the two interfaces he wishes to use.
See also chapter "Data interface".
9.1 RS-232-C/V.24 data interface
HEIDENHAIN guarantees that, if properly connected, the serial data interface RS-232-C/V.24 will
transmit data correctly up to a distance of 20 m between the logic unit and the peripheral unit.
The connection to the peripheral unit is made via a cable adapter which is attached to either the
operating console or the control cabinet. See also under the heading "Mounting dimensions".
This cable adapter (Id.-Nr. 239 758 01) is connected to the logic unit with the HEIDENHAIN cable Id.-
Nr. 239 760 ..
For connection to the peripheral unit HEIDENHAIN offers a standard connecting cable
(Id.-Nr. 274 545 01) , length 3 m.
GND Chassis
RXD Receive data
TXD Transmit data
CTS Clear to send
RTS Request to send
DTR Data terminal ready
GND Signal ground
DSR Data set ready
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
•
•
X21 Data interface RS-232-C/V.24
Id.-Nr. 239 760..
max. 17 m
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
YL
GN
PK
GY
BN
RD
BL
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
•
•
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
GN
YL
GY
PK
BL
RD
BN
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
•
•
WH/BN
GND
TXD
RXD
RTS
CTS
DSR
GND
DTR
Id.-Nr. 274 545 01
3 m
RS-232-C Adapter Block
Id.-Nr. 239 758 01
Peripheral
unit
•
•
••
•
•
•
WH/BN WH/BN WH/BN
If your peripheral unit has a connector layout that differs from the above, the HEIDENHAIN
connecting cable cannot be used.
