3-60 TNC 407/TNC 415/TNC 425 11 PLC inputs/outputs 01.98
X7 Assignment X8 Assignment
Pin number PL 410 B #1 PL 410 B #2 Pin number PL 410 B #1 PL 410 B #2
PL 410 #1 PL 410 #2 PL 410 #1 PL 410 #2
1 O32 O64 1 O48 O80
2 O33 O65 2 O49 O81
3 O34 O66 3 O50 O82
4 O35 O67 4 O51 O83
5 O36 O68 5 O52 O84
6 O37 O69 6 O53 O85
7 O38 O70 7 O54 O86
8 O39 O71 8 O55 O87
9 O40 O72 9 O56 O88
10 O41 O73 10 O57 O89
11 O42 O74 11 O58 O90
12 O43 O75 12 O59 O91
13 O44 O76 13 O60 O92
14 O45 O77 14 O61
1)
O93
1)
15 O46 O78 15 O62
1)
O94
1)
16 O47 O79 16 Control ready
1)
These PLC outputs are not available when analogue inputs are active.
11.3.5 Analogue inputs on the PL 410 / PL 410 B
X15,X16,X17,X18 analogue input
Pin number Assignment
1 –10 V to +10 V
2 0 V (reference potential)
3 Screen
11.3.6 Inputs for thermistors on the PL 410 / PL 410 B
X19,X20,X21,X22 connection for Pt 100
Pin number Assignment
1 I + constant current for Pt 100 (5 mA)
2 U + measuring input for Pt 100
3 U - measuring input for Pt 100
4 I - constant current for Pt 100
5 Screen
