Heinner HAC-HS09KIT++ User Manual

www.heinner.com
45
VII. INSTALLATION INSTRUCTIONS
Distance from ceiling should be
over 200 mm
Distance from wall
should be over 50
mm
Distance from wall should
be over 50mm
Distance from the obstacle
should be over 3000 mm
Distance from floor should be over
2500 mm
Distance from the obstacle should
be over 500 mm
Air intake distance from the
wall should be over 250
mm
Air intake distance from the
wall should be over 250mm
Air outlet distance
from the wall should
be over 500 mm
 Above figure is only a simple presentation of
the unit, it may not amtch the external
appearance of the unit you purchased.
 Installation must be porformed in accordance
with the national wirign standards by
authorized personnel only.
Over 250 mm
