 If an extension drain hose is connecedt to the drain pipe, make sute to thermal
insulated when passing along the indoor unit.
 When the pipes is directed to the right, pipes, power cord and drain pipe should be
thermal insulated and fixed onto the back of the unit with a pipe fixer.
A. Insert the pipe fixer to the slot.
B. Press to hook the pipe fixer onto the base.
Base
Pipe fixer
Insert here
Base
Pipe fixer
Base
Hook here
Large pipe
Drain hose
Small pipe
Large pipe
Small pipe
Drain hose
