According to the diagram (Installation), please follow the installation procedure:
Step 1: Install the four casters (8) on the base (7)
Step 2: Install the body (6) into the base (7), then screw (9) onto base.
Insert the motor bead steel pipe (5) into the body (6).Fasten the real plastic screw.
Step3: Install the rear guard (4) onto the motor (5), then turn guard fastener clockwise.
Step4: Install the fan blade (3) on to the motor axis, tighten the fan fastener anti clockwise.
Step5: Install the front guard (2) and rear guard (4) together, and fasten the rim.
Step6: Pull one side of the fog hose through the ring into fog dish (1) and insert the other side
into mist hose (10).
Now the installation is completed.
OPERATING THE WATER TANK
Stable the mist fan on the ground, and add water inside the water tank according to six
steps below:
Note: Do not take out the water tank before unplugging the power cord. Hot water (40℃
or above) is not allowed to be added into the water tank.
