Main Specifications（2）
Model
Unit
CPD20
CPD25
GC1Li/GD1Li/GD3Li
GC1Li/GD1Li/GD3Li
Rated capacity
kg
2000
2500
Load center
mm
500
Lifting height
mm
3000
Free lifting height
mm
145
Mast tilt angle (fwd/bwd)
(α/β)
°
6/8
Fork size (T×W× L4)
mm
40×122×920
40×122×1070
Wheelbase L1
mm
1550
Tread (front/rear) (W3/W2)
mm
960/950
Overall length (without forks)
L’
mm
2285
2335
Overall width (front/rear) W1
mm
1185
Overall height (mast/overhead
guard) (H1/H4)
mm
1995/2150
Seat height Q
mm
1100
Under-clearance
(H5/H6)
mm
110(at mast)/115(in the middle of the truck
body)
Min. turning radius r
mm
2000
2060
fork adjustment range (outside)
Max/min W5
mm
1030/244
Travelling speed
(loaded/unloaded)
km/h
14.5/15
Lifting speed (loaded/unloaded)
mm/s
DC: 280/490
260/490
AC: 350/510
330/510
Descending speed
(loaded/unloaded)
mm/s
410/490
Gradeability (loaded/unloaded)
%
22/24
20/22
Tyre (front/rear)
23×9-10-16PR/18×7-8-14PR
Traction motor
kW
11.5 (AC)
Pump motor
kW
10.5 (DC)
15 (AC)
Battery
V/Ah
48/500
48/600(optional)
Service weight(with/without
battery)
kg
3615/3215
4035/3635
Battery weight
kg
400
500(optional)
