Helite E-TURTLE User Manual

27
User Guide
3. Remove air from the vest with both hands.
4. Install a new e-cartridge.
y a) Slide the e-cartridge cable in the cartridge holder.
y b) Screw the e-cartridge until the thread is no longer visible.
y c) Connect the e-cartridge.
5. Close the zip or the velcros and the vest can be reused.
CAUTION Do not damage the cable while
screwing the e-cartridge (e.g. by bending
or twisting it). Only connect the e-cartridge
once it is entirely screwed (see example on the
scheme below).
The e-cartridge must be screwed entirely. Do
not apply too much pressure when screwing
in the e-cartridge.
1 1
5
5
3 4
2
1 1
5
5
3 4
2

Helite E-TURTLE Specifications

General

Battery Life	25 hours
Charging Time	3 hours
Type	Airbag Vest
Activation	Electronic
Airbag Inflation Time	0.1 second
Protection Zones	Back, Neck, Chest
SAS-TEC back protector	Included
Compatibility	Motorcycle
Reusability	Reusable after cartridge replacement
Weight	Approximately 1.5 kg (including back protector)
