HELIX DSP PRO MK3 - Page 19

19
en
Connectors and control units
1
3
52 6
1
Lowlevel line inputs
Page 21, point 3
2
Digital inputs (Coaxial & Optical)
Page 22, point 5
.
3
Clipping LED
Page 24, point 1
4
Auto Remote switch
Page 22, point 6
5
Highlevel speaker inputs
Page 21, point 4
6
Power & Remote connector
Page 22, point 7
7
Ground lift switch
Page 25, point 4
8
Control pushbutton
Page 25, point 3
9
Status LED
Page 24, point 2
10
USB input
Page 23, point 8
11
SCP (Smart Control Port)
Page 25, point 5
12
Line outputs
Page 24, point 12
7 10 12118
4
9
