HELIX G FOUR User Manual

19
The limited warranty comply with legal regulations.
Failures or damages caused by overload or im-
proper use are not covered by the warranty. Please
return the defective product only with a valid proof
of purchase and a detailed malfunction description.
Technical specications are subject to change!
Errors are reserved! For damages on the vehicle
and the device, caused by handling errors of the
module, we can’t assume liability. These devic-
es are certied for the use in vehicles within the
European Community (EC).
Technical Data
Warranty Disclaimer
Output power RMS / max.
- @ 4 Ohms ............................................................................... 4 x 80 / 160 Watts
- @ 2 Ohms ............................................................................... 4 x 120 / 240 Watts
- bridged @ 4 Ohms .................................................................. 2 x 240 / 480 Watts
Amplier technology .................................................................. Class AB
Inputs ......................................................................................... 4 x RCA / Cinch
4 x Highlevel speaker input
1 x Remote In
1 x Remote control input
Outputs ...................................................................................... 4 x Speaker output
2 x RCA / Cinch
Frequency response .................................................................. 10 Hz - 40,000 Hz
Bass boost ................................................................................. 0 - 12 dB / 45 Hz
Highpass.................................................................................... 15 Hz - 4,000 Hz adjustable
Lowpass .................................................................................... 40 Hz - 4,000 Hz adjustable
Bandpass................................................................................... 15 Hz - 4,000 Hz adjustable
Slope high- / lowpass ................................................................ Butterworth 12 dB/Oct.
Distortion (THD) ......................................................................... 0.02 %
Signal-to-noise ratio................................................................... 108 dB (A-weighted)
Input sensitivity .......................................................................... Highlevel 2.5 - 14 Volts
RCA / Cinch 1 - 6 Volts
Output voltage RCA / Cinch....................................................... 1 - 6 Volts RMS
Damping factor .......................................................................... 200
Input impedance RCA / Cinch ................................................... 30 kOhms
Input impedance highlevel ......................................................... 12 Ohms
Operating voltage ...................................................................... 9.6 - 16 Volts (max. 5 sec. down to 6 Volts)
Fuse........................................................................................... 2 x 30 A Maxi-fuse (APX)
Dimensions (H x W x D) ............................................................ 57 x 334 x 241 mm / 2.24 x 13.15 x 9.50”
Additional features ..................................................................... Active, adjustable crossover, bass boost,
input mode switch, highlevel input with
automatic turn on function and Advanced
Diagnostics Error Protection (ADEP),
Start-Stop capability, remote control for
channels C & D
