HELIX HLT2500 Assembly Manual

3/ ASSEMBLY
- 7 -
Step 1:
Puttheproductontheoorandremovethetopboxcovertorevealthe
Helix as show above. Where the box corners are printed “OPEN”, cut or tear
theboxandseparatethesecorners.Laythesidesattotheoor
Remove all parts from the box leaving just the main body of the
machine on the bottom of the box. remove all parts from their
plastic bags and organize on the oor beside the Helix.
Step 2:
Attach the End Caps (with HELIX branding ) to the left and right stabilizers.
The branded end caps install on the end farthest from the attaching bolt
holes. Attach Rear End caps (no branding) to the left and right stabilizers at
theendclosestotheattachingboltholes.Theyarefrontandrearspecic
butnotleftandrightspecic.Installthestabilizeradjustmentfeet(4)into
the bottom of the stabilizers and adjust as required.
IMPORTANT:
Do not remove the
Helix from the box
bottom until further
instructed later in
this assembly
manual.
