3/ ASSEMBLY
- 9 -
ASSEMBLY OF THE TRANSPORT PLATE
Step 5:
Find a box or step to place one stabilizer leg of the Helix onto in order to
raise one side off the ground. Install the transport plate with the 4 bolts as
shown.
A5-HLT3500.indd 9 14/12/2012 19:48
