9.1 Replacing the blade
The blade should always be changed when the cable tie can no longer be cut-off neatly or easily.
CAUTION
The blade is sharp and could cause injury.
f Unscrew the nose piece screw 1 (Figure G ) with a screwdriver.
f Remove the nose piece
2 .
f Carefully remove the blade
3 .
f Insert a new and undamaged knife of the same size and design (see section "Spare parts and
accessories"). Observe the correct installation direction.
The installation direction is indicated by the bevelled corner
1 (Figure H ).
f Replace the nose piece.
f Tighten the screw for the blade holder.
10 Taking out of operation
When used for its intended purpose, the application tool will perform continuously without issues.
Should the application tool need to be withdrawn from operation, it must be disposed of correctly
in accordance with the country-specific disposal guidelines.
11 Spare parts and accessories
NOTE
The use of spare parts and accessories not approved by the manufacturer may lead to damage of the
application tool.
f Use only approved spare parts and accessories otherwise warranty claims shall be rendered void.
Spare parts and accessories can be procured direct from the respective HellermannTyton country
representative.
Spare parts / accessories Article number
Blade 110-80037
Fine adjustment tool CALTOOL 110-70089
12 Technical data
TYPE
Dimensions
(L x H x W)
Maximum
strap
width Weight
Article
no.
EVO9 191 x 135 x 33 mm 13.5 mm 0.359 kg approx. 53 to 307 (factory setting) 110-80002
EVO9SP 191 x 135 x 33 mm 13.5 mm 0.359 kg approx. 53 to 307 (factory setting) 110-80003
EVO9HT 191 x 135 x 33 mm 13.5 mm 0.359 kg approx. 120 to 516 (factory setting) 110-80017
= Tension force
