Quick Start Guide NETL ink® Ethernet Gateways 5
3.4 Termination (only NETL ink® PRO PoE and NETL ink® WLAN)
The bus connector with PG socket makes it possible to plug in further bus partici-
pants. The terminating resistor must be inserted (ON) when the NETL ink® is plugged
in at the start or end of a bus segment. If this is not the case, the switch must be in
the OFF position.
3.3 Power over Ethernet connection (only NETL ink® PRO PoE)
When the “Power over Ethernet” function is used, you will see a standard PoE injec-
tor shown in the graph by way of example. Alternatively, it can be installed in the
LAN route to supply the NETL ink® PRO PoE with 48 V.
PoE Injector
To Next Page
