INSTALLATION AND OPERATING INSTRUCTIONS
4211-70 G
Rev. 3
5/9/14
R.D. LD
WARNING
SECTION 7:
SAUNALOGIC CONTROL INSTALLATION & OPERATION
Do not locate benches
over heater. Refer to
Diagram 1 for minimum
clearance of ceiling
above heater.
Minimum clearance
from heater to wooden
surfaces (benches, side
walls, heater fence etc.
refer to Diagram 1).
Mounting brackets
supplied. Provides
proper clearance from
wall behind heater.
Use only copper wire of
the size and type
indicated in the Heater
Specification Chart and
the temperature rating
indicated on the heater
junction box.
All heaters and controls
must be grounded per
NEC to prevent
electrical shock in case
of unit failure.
Electrical outlets or
receptacle must not be
installed in a sauna
room.
A guardrail or fence is
required around the
heater to prevent burns
from accidental contact.
Page 5
SECTION 6: HEATER SCREEN (GUARD RAIL)
Install a wooden heater guard to prevent the sauna bather from
accidentally touching the sauna heater. Install the heater guard rail
with the dimensions shown in Diagram 8.
INSTALLATION ROUGH IN The SaunaLogic control must be
mounted outside the sauna room in a dry environment.
To mount the control cut an 1" hole in the wall behind control
location. Route the control wire from CB PK-1 to the control.
Note: Use the factory supplied cable only! Do not staple
through or otherwise damage the cable! Connect the control
cable to the SaunaLogic and secure the control to the wall by 2
mounting screws provided.
Connect the other end of the control cable through the electrical
access hole on the bottom of the control box and connect it to
"JT1".
OPERATION When power is connected to the heater, the room
temperature setting is automatically preset to 176°F and the
bath time is set to 60 minutes. These settings are adjustable (as
described below) from 125° to 194° and from 0 to 60 minutes
and any changes are remembered by the heater for your next
bath. Should the heaters power be lost then restored, the
settings will return to their default values.
With the power to the heater turned on, press the control
ON/OFF button once. The room temperature will be displayed
on the control. The heater will turn on and begin heating the
room. Once the selected bath temperature is reached, the
heater will turn heater on and off again as needed to maintain
the desired temperature. At the end of the selected time, the
control will turn itself off and the control display will turn off.
SETTING THE TIME AND TEMPERATURE
To set the time, press the control ON/OFF button to turn on the
heater. Press the TIME "+" or "-" buttons on the control to
increase or decrease time for desired setting. The maximum of
time is 60 minutes.
To set the temperature, press the control ON/OFF button to turn
on the heater. Press the TEMP "+" or "-" buttons on the control
to increase or decrease temperature for desired setting. The
maximum temperature is 194°F (90°C).
To Next Page
