Hemisphere GPS V104s - Page 13

8
Chapter 2: Installation
Before installing the V104s use the following diagram to ensure there are no
nearby devices that may cause VHF interference.
Figure 2-1: V104s distance from nearby VHF radios
1.5 m radius at top
(minimum)
1.0 m radius at base
(minimum)
Use these minimum
distances to determine
where to place the V104s
VHF Antenna
