V104s GPS Compass User Guide
15
Flush Mount
The bottom of the V104s contains two holes for flush mounting the unit to a
flat surface (Figure 2-7). The flat surface may be something you fabricate per
your installation, an off-the-shelf item (such as a radar mounting plate), or an
existing surface on your vessel.
Note: Hemisphere GNSS does not supply the mounting surface hardware.
You must supply the appropriate fastening hardware required to complete
the installation of the V104s.
Figure 2-7: Flush mounting with holes in the V104s
Note: You do not necessarily need to orient the antenna precisely as you
can enter a software offset to accommodate for any bias in heading
measurement due to installation.
