V104s GPS Compass User Guide
47
Table B-2: Communication specifications
Item Specification
Serial ports 2 full-duplex RS-232
Baud rates 4800, 9600, 19200, 38400, 57600, 115200
Correction I/O protocol RTCM SC-104
Data I/O protocol
NMEA 0183, Crescent binary
4
Table B-3: Power specifications
Item Specification
Input voltage 8 to 36 VDC
Power consumption ~ 2 W nominal
Current consumption 165 mA @ 12 VDC
Power isolation Isolated to enclosure
Reverse polarity protection Yes
Table B-4: Mechanical specifications
Item Specification
Enclosure UV resistant, white plastic, Geloy CR7520 (ASA)
Dimensions (not including
mount)
Dimensions (including mount)
25.9 L x 12.9 W x 4.5 H (cm)
10.2 L x 5.1 W x 1.8 H (in)
25.9 L x 12.9 W x 12.8 H (cm)
10.2 L x 5.1 W x 5.0 H (in)
Weight (not including mount)
Weight (including mount)
0.42 kg (0.9 lb)
0.51 kg (1.1 lb)
