Service Instructions HERAsafe HS/12/18
• 18 • Valid: 05.2001 / 50060091 / A
4. Replacement of defined spare parts
4.1 List of the defined spare parts, mechanical and electronic components
Position Description Order no. Service instructions
41
Working plate AML 12, HS 12 50057420
Section 4.4
42
Working plate AML 18, HS 18 50057421
Section 4.4
43
Working plate module AM3 HS 12/18 50057445
Section 4.4
44 Exhaust filter guard
50058231
Section 4.2
45
Armrest (2 pieces)
50056570 Figure 1
46
Screw set
50059784 Not illustrated
47 Instruction Manual set 50058532 Not illustrated
Electronic components and accessories
48 Outlet
50057572
Figure 1
49 Outlet cap
50057573
Figure 1
50 Flange outlet
03711067
Figure 1
51 Flange outlet cap
50043783
Figure 1
52
Mains supply cable (unit)
50058427
Figure 2
53
Mains supply cable (internal outlet)
50058427
Figure 2
54 Rubber grommet 5-7 mm
50046053
Figure 1
55 Rubber grommet 7-10 mm
50043857
Figure 1
56 Ballast
50058001
Figure 2
57
Florescent lamp HS 12
50058007
Figure 2
58
Florescent lamp HS 18
50060451
Figure 2
59 Power/Function Key switch
50059901
Section 4.18
60
1-way rocker switch
03001772
Figure 3
61
2-way rocker switch
50048656
Figure 3
62
2-way rocker switch3
50049871
Figure 3
63
1-way rocker switch, button
03001773
Figure 3
64
Light bulb (white)
50011688
Figure 3
65
Light bulb (red)
50011623
Figure 3
66
Light bulb (green)
50046878
Figure 3
67
Light bulb (yellow)
03001781
Figure 3
68
Position switch
50043203
Figure 3
69
Time counter
50055671
Figure 3
70
Relay
50055670
Figure 3
71 Buzzer
50055073
Figure 3
72 Pressure switch
50046861
Figure 3
73 Timer relay
50058217
Figure 3
74
Speed controller
50058141
Figure 3
75
Ballast for UV-C Tube
50060299
76
UV-C Tube
50060298
Foils / Safety labels
77
Foil top
50060185
Section 4.18
78
Foil bottom
50048440
Section 4.18
79
Sheet Safety labels
50058531
User instructions
