Page 10 For technical questions, please call 1-888-866-5797. Item 64751
PARTS LIST AND DIAGRAM
Parts List
Part Description Qty
1 Extension Arm 2
2 Spring 2
3 Steel Lock 2
4 Steel Sleeve 2
5 Lock Knob 2
6 Ф4 Spring 2
7 Ф4*8 Rivet 6
8 Cap 8
9 Mounting Bracket 2
10 Square Nut M8 4
11 M6*55 Bolt 6
12 Lock Handle 2
13 Spring 2
14 Mounting Bracket Base 4
15 Lock Mechanism 2
16 Ф5*60 Spring Pin 4
17 Lock Button 2
18 M6 Cover Nut 6
19 Cam 4
20 Clamp 2
21 Adjustable Clamp 2
22 Washer 2
23 Nut M6 2
24 Bolt M6*30 2
25 Ф8 Washer 4
26 Ф8 Spring Washer 4
27 Bolt M8*50 4
28 Set Screw M5*10 2
29 Bolt M6*45 6
30 Ф6 Spring Washer 4
31 Ф6 Washer 4
32 Extension Arm Base 2
33 Extension Arm Lock 2
34 Locking Handle 2
35 Bolt M6*12 4
36 Handle 1
37 Bolt M6*35 2
38 Nylon Nut M6 6
39 Worktop Support (Handle side) 1
40 Fixed Plate for the Worktop Support 4
41 Bolt M8*10 9
Part Description Qty
42 Square Nut M6 2
43 Handle 1
44 Bolt M6*20 2
45 Carriage Bolt M8*50 4
46 Round Washer 8
47 Washer 4
48 Lock Nut M8 6
49 Limited Block Base 1
50 Guide Bracket 1
51 Worktop Support (Wheel side) 1
52 Wheel 2
53 Wheel Axle 1
54 Ф12 Washer 8
55 Wheel Base 1
56 Bolt M6*15 4
57 Ф6 Washer 4
58 Leg Cover 3
59 Ф4*10 Rivet 8
60 Leg 3
61 Lock Pin Handle 4
62 Ф6 Ring 4
63 Spring 4
64 Lock Pin 4
65 Extension Tube Lock Spring 2
66 Adjustable Foot 1
67 Adjustable Leg Sleeve 1
68 Adjustable Leg 1
69 Roller Cap 4
70 Roller Spring 2
71 Roller Axle 2
72 Roller 2
73 End Cap 20*20 4
74 Workpiece Stop 2
75 Frame End Cap 35*35 2
76 Workpiece Support (Wheel side) 1
77 Workpiece Support (Handle side) 1
78 Beam 1
79 Insert 2
80 Extension Lock Collar 2
81 Ф8 Washer 2
