Page 6 For technical questions, please call 1-888-866-5797. Item 64751
OPERATION
Read the ENTIRE IMPORTANT
SAFETY INFORMATION section at the
beginning of this manual including
all text under subheadings therein
before set up or use of this product.
TO PREVENT SERIOUS INJURY: Read the
miter saw manufacturer’s instruction manual
before use. Ensure that the miter saw is firmly
secured to the stand. Use as a miter saw stand
only – do not use with any other type of power
tool. Do not exceed listed weight capacity. Do
not use on uneven or slippery surfaces.
Adjusting Extension Arms
1. Raise Locking Handle, then pull out or
push in Extension Arm to desired length.
2. Lower Locking Handle.
Extension
Arm
Locking
Handle
Adjusting Workpiece Supports
1. Workpiece Height:
a. Loosen Lock Knob.
b. Raise or Lower Workpiece Support.
c. Tighten Lock Knob
2. Workpiece Stop: Use when cutting
multiple workpieces the same length.
CAUTION! Do not use both Workpiece Stops
at the same time or saw blade may bind
in the workpiece when cutting.
Lock
Knob
StopRoller
Workpiece
Stop
Storage
1. Loosen Lock Knob and raise
Workpiece Support all the way.
2. Tighten Lock Knob.
Storage
Feet
3. Tip Stand so that it is resting on Storage Feet.
4. Press the Lock Pin Handles on
each Leg and fold them in.
5. Roll Stand to storage area.
