Hercules HCB751B - Parts List and Diagram

Page 10 For technical questions, please call 1-888-866-5797. Item 57549
PARTS LIST AND DIAGRAM
Parts List
Part Description Qty
1 Plug 2
2
Hex Socket Pan Head Screw
4
3
Gear Box(Left)
1
4
Guide Pin
2
5
Phillips Pan Head Flange Screw
7
6
Hex Lock Nut
2
7
Located Block
1
8
Reciprocating Rod Assembly
1
9
Bearing Bushing
1
10
Located Block
1
11
Hex Socket Screw
2
12
Bearing Bushing
1
13
Felt
2
14
Clamp
1
15
Cross Grooved Disc Head Screw
1
16
Sealer
1
17
Output Shaft
1
18
Needle Bearing
1
19
Cylindrical Pin
1
20
Gear
1
21
Flat Washer
1
22
Deep Groove Ball Bearing
1
23
Retaining Ring
1
24
Deep Groove Ball Bearing
1
25
Retaining Ring
1
26
Plug
1
27
Cylindrical Pin
2
28
Pressing Plate
1
29
Hex Socket Head Screw
6
30
Self-Tapping Plum Head Screw
4
31
Pressing Plate
1
32
Screw
1
33
Shaft Lock
1
Part Description Qty
34
Compression Spring
1
35
Button
1
36
Gear Box(Right)
1
37
Shoe
1
38
Pressing Plate
1
39
Quick-Change Button
1
40
Quick Change Torsional Spring
1
41
Gearbox Insulator
1
42
Felt
1
43
Retaining Ring
1
44
Deep Groove Ball Bearing
1
45
Pressing Plate
1
46
Housing(Left)
1
47
Supporter
1
48
Rotor Assembly
1
49
Stator Assembly
1
50
Housing(Right)
1
51
Self-Tapping Screw
2
52
Deep Groove Ball Bearing
1
53
Hex Lock Nut
2
54
Hook
1
55
Shaft Sleeve
1
56
Compression Spring
1
57
Elastic Cylindrical Pin
1
58
Mounting Sleeve
1
59
Hex Socket Screw
2
60
Handle(Left)
1
61
Button
1
62
Electronics Assembly
1
63
Handle(Right)
1
64
Pan Head Self Tapping Screw
8
65
Compression Spring
1
